Product features:
1. Strong program editing, task concurrently: can meet all kinds of project engineering application and the needs of different industries.
2. Convenient management: the cluster management, support the end user and multistage grouping, allows users to multistage permissions Settings.
3. Easy to extend: modular design, easy to software function extension; Hardware support distributed deployment, when achieved when the load on the server can be set up extension server; Each server load capacity to support 2000 terminal connection online at the same time.
4. A variety of networking: support wired and wireless (WiFi, 3 g) and other access methods.
5. Data security: to provide high level of user authority management, without the audit task will not be released.
6. Information real-time release: immediate release emergency information.
7. Separately display content: a screen can play video and images at the same time.
8. Content group play: with screen play different content, different screen play the same content.
Information security assurance: using special encryption technology, can control all the platform approval program never play on the terminal.
| LED type | SMD0404 |
| Module pixel composition | 1R1G1B |
| scanning method | 24S |
| Resolution | 96x48 (W x H) |
| Point spacing | 2.5 mm |
| Module size(mm)W*H*D | 240 x 120 x 10 |
| Box module arrangement | 2 x 4 |
| Resolution(W x H) | 192 x192 |
| Box size(mm)W*H*D | 480 x480 x 98 |
| Box area(㎡) | 0.2304 |
| weight（kg） | 8 |
| Supply voltage | AC 220/110 ± 10 %，47~63Hz |
| Maintenance mode | Behind the maintenance |
| Horizontal perspective | 140° |
| Vertical perspective | 140° |
| brightness | ≥1,000cd/㎡ |
| Pixel density | 160,000/㎡ |
| Certification | UL, CE, ETL, ROSH, CCC |
| Contrast | 3,000∶1 |
| Operating temperature | -20º C to +50º C |
| Working humidity | 20 % to 90 % |
| Life (50% brightness) | 100,000h |
| Color processing ability | 14 bit |
| Colour | 281 trillion |
| refresh rate | ≥2,400Hz |
| Frame rate | 60 fps |
| Brightness level | Manual 100, automatic 16 level
|
